Engineered timber flooring is a popular choice for Australian homes, apartments, renovations and commercial projects because it combines the appearance of natural timber with greater dimensional stability than traditional solid timber flooring.

But a quality engineered timber floor is only as good as the system underneath it.

Poor subfloor preparation, excessive moisture, inadequate flatness, incorrect adhesive selection or insufficient expansion allowance can lead to problems such as hollow spots, movement, gaps, cupping, lifting and adhesive failure.

So, how do you install engineered timber flooring correctly?

This guide walks through the key stages of a professional engineered timber flooring installation in Australia — from checking the subfloor to choosing between floating and glue-down installation.

Important: Always follow the flooring manufacturer's installation instructions, adhesive technical data sheet and applicable Australian requirements for the specific project.

1. Choose the Right Installation Method

Engineered timber flooring is generally installed using one of three methods:

Floating Installation

With a floating floor, the engineered timber boards are connected to each other but are not permanently bonded to the subfloor.

An appropriate underlay is installed beneath the flooring system.

Floating installation can be efficient and is suitable for flooring products specifically designed for this method.

Glue-Down Installation

In a glue-down installation, adhesive is applied directly to the prepared subfloor and the engineered timber flooring is bonded to it.

This method provides a more stable connection between the flooring and substrate and is commonly used for professional installations, particularly where acoustic performance, stability or large-format flooring is important.

The adhesive must be compatible with both the engineered timber flooring and the substrate.

Mechanical Fixing

Depending on the product and substrate, some engineered timber flooring can also be mechanically fixed to suitable timber-based subfloors.

However, not every engineered timber product supports every installation method.

Always check the flooring manufacturer's specification before selecting the installation system.

2. Inspect the Subfloor Before Installation

The subfloor is the foundation of the entire flooring system.

Before installing engineered timber flooring, check that the substrate is:

• Structurally sound
• Clean
• Dry
• Stable
• Sufficiently flat
• Free from contaminants
• Suitable for the selected installation method

Concrete slabs, plywood, particleboard, existing timber flooring and other substrates may require different preparation procedures.

Do not assume that a visually clean concrete slab is ready for flooring.

A substrate can look dry while still containing significant moisture internally.

This is particularly important in Australian construction, where new concrete slabs, renovations and varying climate conditions can create very different drying environments.

Recent Australian flooring guidance continues to emphasise moisture assessment and proper subfloor preparation before timber flooring installation.

3. Test Moisture Before Installing Timber Flooring

Moisture is one of the most important factors in engineered timber flooring installation.

Concrete continues to release moisture as it dries. If flooring is installed before the substrate is sufficiently dry, moisture can become trapped beneath the flooring system.

This may contribute to:

• Adhesive failure
• Timber movement
• Cupping
• Gaps between boards
• Peaking
• Swelling
• Mould or microbial growth

For this reason, professional installers should assess the moisture condition of the substrate before installation.

Different flooring manufacturers and adhesive systems specify different acceptable moisture limits, so there is no single number that should automatically be applied to every project.

For example, some Australian engineered timber installation instructions specify concrete conditions around 75% relative humidity, while other systems may specify different limits or testing methods.

The correct approach is:

Test → Compare with the flooring and adhesive manufacturer's requirements → Correct the substrate if necessary → Install.

For a deeper explanation of moisture testing, see our guide:

Moisture Testing Before Timber Flooring: Why It Matters Before Installation

4. Make Sure the Subfloor Is Flat

Engineered timber flooring needs a stable and sufficiently flat surface.

Uneven areas can create unsupported sections underneath the boards, which may contribute to:

• Hollow-sounding areas
• Board movement
• Excessive stress on joints
• Uneven adhesive contact
• Premature flooring failure

Many Australian installation guides use approximately 3 mm over a 3 m straight edge as a reference for engineered timber flooring, although the exact tolerance should always be checked against the flooring manufacturer's requirements.

If the subfloor is uneven, preparation may include:

1. Grinding high spots
2. Repairing cracks or damaged areas
3. Priming the substrate
4. Applying a suitable self-levelling compound
5. Allowing the prepared surface to cure according to the product requirements

For timber substrates that require levelling, use a primer specifically designed for the substrate before applying a compatible levelling compound.

For example, LEVELMAX Primer X-Timber is designed for timber floor systems before cementitious self-levelling compounds.

5. Prepare the Surface Properly

Once the substrate has been confirmed as suitable, prepare the surface according to the selected installation system.

For concrete substrates, preparation may include mechanical grinding or other approved preparation methods to remove:

• Dust
• Paint
• Oil
• Grease
• Weak surface material
• Adhesive residue
• Construction contamination

The substrate should then be thoroughly vacuumed.

Do not simply cover a contaminated surface with adhesive.

A strong adhesive cannot compensate for a weak or contaminated substrate.

The same principle applies to levelling compounds.

A professional flooring system is only as reliable as the weakest layer underneath it.

6. Correct Uneven Timber Subfloors

Timber and particleboard substrates require particular attention.

Before installing engineered timber flooring, check:

• Board stability
• Fixing quality
• Joint movement
• Moisture content
• Surface contamination
• Overall flatness

Loose or unstable sections should be repaired before flooring installation.

Where levelling is required over timber substrates, the correct primer is important because cementitious levelling compounds and timber substrates behave differently.

A timber-specific primer can help establish the correct interface between the substrate and levelling system.

LEVELMAX Primer X-Timber is specifically formulated for this application, while LEVELMAX ProFlow Self-Levelling Compound can be used as part of a compatible substrate preparation system.

7. Allow the Flooring to Reach the Installation Environment

Engineered timber is more dimensionally stable than solid timber, but it is still a timber-based product.

Timber flooring should be allowed to adjust to the installation environment according to the flooring manufacturer's requirements.

Temperature and humidity can influence the dimensions of the boards.

Australian guidance does not necessarily support treating every engineered timber product in exactly the same way. Some manufacturers recommend storing the flooring in the installation environment for around 48 hours, while others provide different requirements.

Therefore, do not rely on a generic "48-hour acclimatisation rule" without checking the product instructions.

Instead:

Follow the flooring manufacturer's storage and acclimatisation requirements.

The installation area should also be protected from uncontrolled moisture and major temperature fluctuations.

8. Plan the Layout Before Installing

Before applying adhesive or connecting boards, plan the flooring layout.

Check:

• Starting wall
• Board direction
• Doorways
• Hallways
• Fixed structures
• Room transitions
• Final board widths
• Expansion gaps
• Natural variation between boards

For long hallways, boards are often positioned along the length of the space to create a visually continuous installation.

Mix boards from different cartons during installation where recommended by the manufacturer. This helps distribute natural variations in colour, grain and tone throughout the finished floor.

Also inspect every board before installation.

If a board has a visible manufacturing defect, do not install it.

9. Allow for Expansion

Timber flooring responds to changes in temperature and humidity.

Engineered timber is more stable than many solid timber products, but it still moves.

Expansion gaps should therefore be maintained around:

• Perimeter walls
• Columns
• Door frames
• Pipes
• Fixed vertical structures
• Other restrictions

The required gap varies between flooring systems.

Some Australian engineered timber products specify approximately 8–12 mm, while others require different allowances.

The important point is:

Never guess the expansion gap. Follow the flooring manufacturer's specification.

The flooring should not be trapped tightly between fixed structures.

10. Installing Engineered Timber Flooring With Adhesive

For glue-down installation, the adhesive becomes a critical component of the flooring system.

The adhesive should be selected according to:

• Flooring type
• Timber species
• Substrate
• Moisture conditions
• Installation method
• Project requirements
• Manufacturer compatibility

For professional timber flooring applications, modern MS Polymer adhesives can provide a flexible bond while accommodating normal movement within the flooring system.

One example is the LEVELMAX BondMax MS80 Timber Flooring Adhesive.

BondMax MS80 is designed as a multi-function timber flooring adhesive system, combining:

• Flooring adhesive
• Moisture barrier
• Acoustic-rated performance
• Timber stabilisation

However, an adhesive should never be used as a substitute for proper moisture testing.

Moisture testing comes first. Adhesive selection comes second.

11. Apply the Adhesive Correctly

For glue-down installation, adhesive should be applied using the correct trowel and coverage specified by the adhesive manufacturer.

The objective is to achieve consistent adhesive transfer across the required installation area.

Avoid:

• Applying too much adhesive
• Applying too little adhesive
• Allowing adhesive to skin over
• Working outside the adhesive's open time
• Using an incorrect trowel
• Installing over contaminated surfaces

The correct trowel size is particularly important because it controls adhesive coverage and therefore affects the performance of the flooring system.

For professional installers, adhesive coverage should always be checked against the product's Technical Data Sheet.

12. Install the First Rows Carefully

The first rows determine the alignment of the entire floor.

Before fixing the boards:

1. Establish a straight reference line.
2. Confirm the required perimeter expansion gap.
3. Check the starting wall.
4. Dry-fit the first section where appropriate.
5. Confirm the board direction.
6. Begin installation according to the manufacturer's jointing requirements.

A small alignment error at the beginning can become very noticeable after several metres.

Take the time to establish a straight and stable starting point.

13. Continue Across the Room

As installation progresses:

• Maintain consistent board alignment.
• Maintain expansion gaps.
• Stagger end joints according to the flooring manufacturer's instructions.
• Mix boards from multiple cartons where recommended.
• Keep adhesive within its working time.
• Remove adhesive contamination immediately according to the manufacturer's instructions.

Avoid forcing boards into position.

The flooring should sit correctly within the designed installation system rather than being mechanically forced into place.

14. Finishing Around Doors and Fixed Structures

Door frames and architraves are often overlooked during flooring preparation.

Where appropriate, door jambs can be undercut so that the engineered timber flooring can slide underneath rather than requiring an awkward cut around the frame.

The result is a cleaner visual finish and allows the flooring to maintain the required movement allowance.

However, fixed structures such as kitchen cabinetry and islands require particular attention.

Whether these can be installed over the flooring depends on the flooring manufacturer's system and installation method.

Always follow the project-specific requirements.

15. What About Underfloor Heating?

Engineered timber flooring can be used with some underfloor heating systems, but compatibility must be confirmed before installation.

The flooring, adhesive, levelling compound and heating system must all be compatible.

Important factors include:

• Maximum floor surface temperature
• Heating system type
• Moisture condition of the slab
• Heating commissioning procedure
• Adhesive compatibility
• Gradual temperature changes

For example, some Australian engineered timber systems specify a maximum floor surface temperature of around 26°C.

Never assume that an adhesive or flooring product is automatically compatible with every type of underfloor heating.

16. Protect the Newly Installed Floor

The installation is not finished simply because the last board has been installed.

On active construction sites, the new floor should be protected from:

• Heavy traffic
• Construction dust
• Impact
• Water
• Paint
• Plaster
• Other trades

Use a suitable breathable floor protection system where required.

Avoid trapping moisture underneath temporary protection.

This is particularly important in new construction and renovation projects where other trades may continue working after the timber floor has been installed.

The 7 Most Common Engineered Timber Flooring Installation Mistakes

1. Installing over a wet slab

A slab can look dry while still containing excessive internal moisture.

2. Skipping subfloor preparation

Small substrate defects can become major flooring problems.

3. Ignoring flatness

Uneven areas can create hollow spots and movement.

4. Choosing the wrong adhesive

Not every adhesive is suitable for engineered timber flooring.

5. Using the wrong trowel

Incorrect adhesive coverage can compromise bond performance.

6. Forgetting expansion gaps

Timber needs room to respond to environmental changes.

7. Installing before the site is ready

Painting, plastering, wet trades and uncontrolled humidity can affect the flooring system.

A Better Way to Think About Engineered Timber Flooring

A successful installation is not simply:

Flooring + adhesive

It is a complete system:

Subfloor → Moisture Control → Preparation → Levelling → Adhesive → Flooring → Expansion → Protection

Every layer affects the next.

This is why professional installers should consider the complete flooring system rather than choosing individual products in isolation.

LEVELMAX Flooring System for Engineered Timber Installation

For projects requiring substrate preparation and timber flooring installation, LEVELMAX provides a complete flooring system covering preparation through to final bonding.

The system includes:

Primer → Self-Levelling → Timber Adhesive

For example:

Primer X
↓
ProFlow Self-Levelling Compound
↓
BondMax MS80

For timber substrates, Primer X-Timber can be used as the appropriate primer within the substrate preparation process.

The benefit of a system approach is straightforward: each stage is considered as part of the overall flooring build-up rather than as a standalone product.

You can also explore the complete LEVELMAX Flooring System for professional flooring applications.

Final Thoughts

Installing engineered timber flooring correctly requires more than simply laying boards across a room.

The most important work often happens before the first board is installed.

A professional installation starts with:

1. Checking the substrate
2. Testing moisture
3. Correcting uneven areas
4. Preparing the surface
5. Selecting the correct installation method
6. Choosing a compatible adhesive
7. Maintaining expansion allowances
8. Following the flooring manufacturer's installation requirements

When these fundamentals are right, the flooring system has a much better chance of delivering the stability, appearance and long-term performance expected from engineered timber flooring.

For Australian flooring contractors, builders and renovation professionals, the goal should not simply be to install the floor.

Installation should also take into account the applicable building requirements for the project, including the current NCC 2025 framework where relevant.

It should be to build a flooring system that performs from the substrate up.

Need help choosing the right flooring system for your project? Contact LEVELMAX for product and technical support.
